We offer customization of wire basket cable trays for various cable management application. A variety of cable trays are available to meet clients specific requirements for power and data separation. Below are some case of special wire basket cable trays that we currently offer:
G Type Mini Basket Cable Tray
The G Type mini basket cable tray is specially designed for small-diameter cables or installations with limited number of cables. Tray is easily modified, requiring only 2 cuts with hand wire cutters for on-site installers to make full range of horizontal or vertical changes. Stocked in 10 ft lengths, 50 x 50 mm tray features modified wire design that allows it to lie flat when mounted. Unit's open and airy construction makes it easy to clean and fast to dry.
This versatile tray is quick to install and easy to modify-just two simple cuts with hand wire cutters allow on-site installers to make a full range of horizontal or vertical changes. Uniquely designed, the G type mini tray offers maximum function with the greatest variety of directional changes available in one piece.
Stocked in 3m lengths, this 50 x 50 mm tray features a modified wire design that allows it to lie flat when mounted. Its open and airy construction makes it easy to clean and fast to dry. For especially demanding applications, the mini G wire tray is available in a variety of finishes including stainless steel.
Under Desk Wire Mesh Cable Tray
The under desk wire mesh cable tray would keep your cables neat, tidy and organised. GPO and data provisions can be run on the cable trays with cables brought through a scollop or cable port in the desktop The handy ventilating grid pattern allows for air circulation and also prevents dust, debris and other contaminates from becoming trapped inside the tray.
They can be made of single layer or double layer.
Single Layer Dimensions: Internal Depth - 66mm; Total Height - 125mm; Length - 1550mm; Basket Height - 40mm
Double Layer Dimensions: Internal Depth - 87mm; Total Height - 240mm; Length - 1550mm; Basket Height - 40mm
The desk cable management cable basket tray have features of:
- Mounts easily under the desk or from the ceiling.
- Cables can be secured to clamps or ties.
- Smooth powder coated finish to protect cables.
- Keeps cable cool with ventilated design.
- Segregated baskets for power and data
Customization Material or Finishing: Carbon Steel, Stainless Steel Grade 304/316/316L/Powder Coated, Zinc Plated, Electrolytic Polishing.
