Choose Right Length for Wire Basket Cable Trays

As per NEMA VE 1, Metal Cable Tray Systems, cable tray typical lengths, not including connectors, are:
(a) 3m ± 5mm (10 ft ± 3/16 in.);
(b) 3.66m ± 5mm (12 ft ± 3/16 in.);
(c) 6m ± 9mm (20 ft ± 5/16 in.); and
(d) 7.32m ± 9mm (24 ft ± 5/16 in.).

Actually, we rarely have clients use 3.66m and 7.32m long cable basket trays. Very few clients would use 6m long basket trays. But the 6m length would cause many issues. Firstly, 6m long cable trays is difficult to do galvanizing. Most electrical galvanizing pools are not long enough to lay in very long cable trays. Secondly, they cannot be lifted by a forklift since manufacturing to warehouse stocking. Thirdly, they will be not flexible for transportation nor installation, as they are too heavy and too long.

Our Bonet wire mesh / basket cable tra[……]

Read more

Other Bonet Cable Tray Accessory Solutions

In previous articles, we had introduced our wire mesh cable tray accessories for connecting, ceiling mounting, wall mounting, floor & on-cabinet mounting. There are still other accessories to make cable tray installing more flexible and more wide fitting.

fix wire mesh cable tray on machine, wall, floor or other solid surface directly.

CCP allows basket cable trays to be fixed on machine, wall, floor or other solid surface directly.

Central Holding

CHD allows to support cable trays from central area. It is particularly suitable for width limit projects.

cable exit guider plate

CGD is a common used accessory. It can help cables ran out from cable tray and drop to cabinets with protective radian.

wire mesh cable tray cover

CVR is cover specially designed for cable basket. We can fix the cover onto cable baskets without any bolt & nut.

Cable Basket Tray Divider

DVR allows running power cables and data cables in same cable[……]

Read more

Season’s Greeting from Bonet Cable Tray

2021 Christmas Day is coming. And the new year will soon begin. Hereby we wish all our customers happiness and prosperity in the year ahead. May your Chirstmas be filled with special moments, warmth, peace and happiness, and wishing you all the joys of Christmas and a year of happiness.

We expect to continue our cooperation in the new year.

[……]

Read more

Bonet Cable Tray Solution for Floor & On-rack Mounting

Normally we can use same solution for on floor and on rack mesh cable tray mounting accessories.

Firstly let’s see the most widely used item.

EFS cable basket rack mounting kit

We offer EFS100 to EFS600 which meet basket cable tray width from 100mm to 600mm. Standard supporting height is 120mm or 170mm. The support feet height can also be customized according to project installing requests.

This 100FSD is designed for 100mm wide mesh cable trays. While it can also be used for larger sizes with using two or three 100FSD in one row.  And it can be used in a left-right-left way for cable tray size like 150mm wide.

50FSD is the bottom supporting kit specially designed for 50mm wide cable basket trays.

Many data center projects will require to install wire mesh cable trays on raised floor. Two VCNs[……]

Read more

Bonet Cable Basket Tray Wall Mounting Accessories

In Bonet, we have several wall mounting accessories for customers to choose. What are the differences of those items? When shall I use them? Today let’s talk about how to choose our wall mounting accessories.

SPB Spider Bracket

SPB spider bracket is the suitable wall supporting bracket for small size cable basket tray, especially for 50mm wide size. If there are only few cables inside, 150mm wide cable basket can also use this accessory as wall mounting.

LWB Wall Bracket

LWB L type wall bracket  is the economical accessory for basket cable tray size from 100mm to 300mm wide. You can lock the trays onto cable basket without any bolt nor any locking couplers.

CRP Cable Basket Bracket

CRP reinforced bracket is similar to LWB. It is also designed for basket cable tray size from 100mm to 300mm wide. The difference is CRP have coupler[……]

Read more

Bonet Cable Basket Ceiling Mounting Accessories

Ceiling support is the most common mounting solution for cable baskets. We offer four ceiling supporting accessories for overhead installations.

Bonet OBR Hanger

OBR is the most popular choice for cable basket ceiling mounting installations. There is no need of using bolts and nuts to fix the cable baskets. And the basket cable tray would never move transversely. It fits cable basket width from 100mm to 600mm.

Bonet MBR Ceiling Support

MBR is more often made by pre-galvanized steel. Its weight loading capacity is thinner than OBR. We don’t recommend to use MBR for heavy duty projects. The biggest advantage for MBR is it can be made with 1m length. Clients can cut it into suitable length by themselves.

Bonet CNL Cable Basket Support

CNL has best support capacity. If cable basket size is bigger than 600mm, or the cable basket need to carry a h[……]

Read more

Bonet Wire Mesh Cable Tray Connector

Bonet cable tray offers several connecting solutions for its wire mesh cable tray systems. Let’s see how to select suitable connector for the project.

https://www.cnbonet.com/wire-mesh-cable-tray/couplers.html

Bonet kk34 wire mesh cable tray coupler

KK34 is the most common recommended item for connecting two pieces of wire mesh cable trays. Suitable for 4mm and 5mm wire diameter. Also can be used for making bends, tees and crossed.

Bonet SBR strengthening coupling bar

SBR is used for connecting wire mesh cable tray straight sections. Though purely use KK34 coupling kit is also available, cable tray systems mounted with SBR coupling bars will getting much more solid.

SPL boltless cable basket connector

SPL is the boltless solution similar as SBR. It can shorten installing time with suitable pulling tool. To matching SPL, BTC is the boltless solution to replace KK34 at the botto[……]

Read more

Powder Coated Cable Basket Tray

Powder coated cable basket tray is widely used in data centers and server rooms. It can keep tray color same as server racks’.  That is one advantage of black powder coated basket trays. From my point of view, the biggest advantage of powder coated cable basket trays is color. We can manage cables more efficiently by using different colors.

Powder coated finishing also has some disadvantages. For example, the plastic coating is more easlily to get scratched. It would require separation of each piece. Thus more packaging material shall be used which is not environmentally friendly. And we recommend customers to choose powder coating after zinc galvanized. This could get rid of partial rusting after powder coating scratched. Another disadvantage of powder coated cable basket is grounding.[……]

Read more
